DESCRIPTION
Introducing the Hikmicro Stellar SH35 3.0 4.2x-24.2x Thermal Imaging Riflescope – 384×288. A high-performance thermal image riflescope designed for precise hunting in diverse environments and conditions. Featuring a 384 x 288 resolution thermal detector with a 12 m pixel interval, it ensures exceptional sensitivity with a NETD of less than 15 mK (at 25C). This advanced thermal detector is complemented by the latest image processing algorithm, Image Pro 2.0, and the Hikmicro Shutterless Image System (HSIS), which guarantees uninterrupted imaging, allowing users to easily identify targets under various lighting and weather circumstances.
The scope is equipped with a 35 mm, f1.0 lens and offers a remarkable detection range of up to 1,800 meters, ensuring that users can spot distant targets with clarity. Its 2,560 x 2,560 resolution AMOLED display (1.03 inches) enhances the viewing experience with bright, detailed visuals, making it easier to identify targets quickly and accurately. The magnification range of 4.2x to 24.2x allows for fine adjustments, and the continuous zoom feature facilitates seamless transitions between magnification levels. The field of view at 100 meters is 7.5 x 5.7, providing essential situational awareness for field and forest hunting. The focus is adjustable via a focus ring, with the minimum focusing distance set at 3 meters. Constructed for durability, the SH35 3.0 offers high shock resistance (up to 1,000 g/0.4 ms) and an IP67 protection level, ensuring that it is resilient against dust and water. Weighing 800 grams without the external battery and measuring 410 mm x 85 mm x 69.4 mm, it is designed for stability and ease of handling.
Powering the device are two rechargeable lithium batteries (internal) complemented by one replaceable and rechargeable 18650 battery (external), providing an impressive continuous operating time of 9 hours even at sub-zero temperatures. The Type-C power supply supports quick charging (QC3.0) and ensures efficient power management for extended use. The SH35 3.0 also features onboard video recording and audio recording capabilities, allowing users to capture and document their experiences. Additional functions include snapshot capture, recoil-activated recording, and distance measurement, making it a comprehensive tool for hunters and outdoor enthusiasts. Its built-in storage of 64GB accommodates a substantial amount of data, while features like Hot Spot, PIP (Picture-in-Picture), and Hot Tracking enhance target detection and tracking efficiency.
FEATURES
384 x 288 resolution
12 um thermal detector
High sensitivity thermal module netd35 mm, f1.0 lens
Detection range up to 1,800 m
2,560 x 2,560 resolution 1.03-inch oled display
Hikmicro shutterless image system (hsis)
Rechargeable internal batteries and external battery, 9h continuous operation
High shock resistance up to 1,000 g/0.4 ms
SPECIFICATIONS
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 384 x 288
Frame Rate 50 Hz
Pixel Interval 12 um
Response Waveband 8 um to 14 um
Netd Less than 15 mK (at 25C, F 1.0)
Lens (Focal Length) 35 mm, F1.0
Focus Mode Focus Ring
Detection Range 1,800m
Focusing Distance 3 meters
Magnification 4.2x – 24.2x, Support 1x step value of continuous zooming
Field Of View (Hxv), Degrees / M At 100 M 7.5 x 5.7/13.1 m x 10.0 m
Image Display
Display 2,560 x 2,560, 1.03-inch OLED
Palettes Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
Exit Pupil 6 mm
Eye Relief 45 mm
Diopter (Range) -5D to 3D
Brightness Adjustment Yes
Tone Adjustment Cold, Warm
Contrast Adjustment Yes
Zoom Pro Yes
Image Pro 2.0 Yes
Hsis (Hikmicro Shutterless Image System) Yes
System
Record Video On-board Video Recording
Capture Snapshot Yes
Audio Recording Yes
Recoil-Activation Recording Yes
Standby Mode Yes
Storage Built-in EMMC (64 GB)
Pip Yes
Hotspot Yes
Hot Track Yes
Distance Measurement Yes
Zeroing Profiles 5
Recoil 1,000 g/0.4 ms
Freeze Zeroing Yes
Local Album Yes
Power Supply
Battery Type Two rechargeable Lithium batteries (internal), one replaceable and rechargeable 18650 battery (external)
Battery Operating Time 9 hours continuous running (at -20C, Zoom Pro, LRF on)
Type-C Power Supply 5 V DC/2 A, USB Type-C interface Supports QC3.0
General
Mounting Standard 30 mm
Protection Level IP67
Dimension 410mm x 85 mm x 69.4mm
Weight 800 g without external battery
Working Temperature -30C to 55C (-22F to 131F)
Centre Height 32 mm
